Basic Info.
Model NO.
TANGLIAN
Storage Medium
Moncombustible/Nontoxic
Pressure Level
Low Pressure (0.1MPa≤p<1.6MPa)
Condition
New, New
Customized
Customized
Certification
ISO9001, QS, UL, GS, TUV, GB
Tank Marerial
Metal Tank
Type
Middle Pressure Storage & Transportation Equipment
Storage Objects
Solid, Liquid
After-Sales Service
1 Year Free Parts
Agitator Model
Combined Agitator
Tower Reactor Type
Packed Tower Reactor
Heat Transfer Structure
Jacketed
Automatic Grade
Semi-Automatic
Capacity
10 L-10000 L
Structure
Kettle
Heating
Oil or Water or Electric
Design Life
6 Years
OEM
Yes
Jacketed
with Cooling/Heating Jacket
Glass Thickness
0.8 mm to 2.0 mm
Transport Package
Expert Export Transportantion
Specification
customized
Trademark
Tanglian
Origin
Zibo City, Shandong Province, China
HS Code
8419
Production Capacity
1000set/Year
Product Description
Shandong Tanglian Chemical Equipment Co.,Ltd.,founded in 1998,is a one of the longest -established Chemical Reactors factories in China , and now we are acting as a group with 7 branches companies .
Our main products include:
Glass Lined Reactor(GLR) , GMP Stainless Steel (SS) Reactor ,Mild Steel ( MS ) Reactor , High Borosilicate Glass Reactor , and related equipment such as Tank, Dryer , and Condenser etc..
And other chemical equipment from 5L to 50000L as below :
Condensers, Distillation columns, Measurement tanks, Storage tanks, Heat ex changer, Stainless steel tanks, Glass lined receivers and vessel, Distillation tanks, Wiped film evaporators, Vacuum dryers, Pressure vessel.
Glass Lined (Enamel / GLR) / GMP Stainless Steel (SS) / PTFE Chemical Reactor / Storage /Mix /Stirring Tank
Glass Lined / Stainless Steel Laboratory Chemical Reactor , Distillation Tank , Measurement Tank , Electric Heating Reactor ,Heat Exchanger
Main Structure Design of K Type Glass-lined Reactor
| pecification Model | K-50 | K-100 | K-200 | K-300 | K-500 | K-1000 | K-1500 | K-2000 | K-3000 | K-5000 | K-6300 | |
| Nominal Capacity (L) | 50 | 100 | 200 | 300 | 500 | 1000 | 1500 | 2000 | 3000 | 5000 | 6300 | |
| Actual Capacity (L) | 71 | 128 | 247 | 369 | 588 | 1250 | 1720 | 2160 | 3380 | 5224 | 6735 | |
| Heat Exchange Area(m2) | 0.34 | 0.66 | 1.26 | 1.75 | 2.64 | 4.54 | 5.34 | 7.02 | 8.61 | 13 | 16.4 | |
| Dimension mm | D1 | 500 | 600 | 700 | 800 | 900 | 1200 | 1300 | 1300 | 1600 | 1750 | 1750 |
| D2 | 600 | 700 | 800 | 900 | 1000 | 1300 | 1450 | 1450 | 1750 | 1900 | 1900 | |
| D3 | 706 | 816 | 918 | 1028 | 1130 | 1468 | 1622 | 1622 | 1964 | 2152 | 2152 | |
| Hl | 265 | 300 | 345 | 380 | 405 | 480 | 505 | 505 | 580 | 617 | 617 | |
| H2 | 400 | 500 | 700 | 800 | 1000 | 1200 | 1400 | 1745 | 1740 | 2050 | 2997 | |
| H3 | 300 | 320 | 350 | 350 | 400 | 500 | 500 | 500 | 600 | 670 | 700 | |
| H4 | 945 | 945 | 953 | 1154 | 1154 | 1276 | 1276 | 1276 | 1326 | 1326 | 1475 | |
| H | 1705 | 1845 | 2110 | 2440 | 2700 | 3000 | 3310 | 3650 | 3785 | 4800 | 5580 | |
| Transmission model | BLD-1 | BLD-1 | BLD-1 | BLD-2 | BLD-2 | BLD-3 | BLD-3 | BLD-3 | BLD-3 | BLD-4 | BLD-4 | |
| Type of Agitators (r/min) | Frane(Anchor)Type | 63/85 | 63/85 | 63/85 | 63/85 | 63/85 | 63/85 | 63/85 | 63/85 | 63/85 | 63/85 | 63/85 |
| Turbine Type | 130 | 130 | 130 | 130 | 130 | 130 | 130 | 130 | 130 | 130 | 130 | |
| Glass-lined nozzle | a | 80 | 80 | 125 | 125 | 150 | 300x400 | 300x400 | 300x400 | 300x400 | 300x400 | 300x400 |
| b | 70 | 70 | 80 | 100 | 100 | 125 | 125 | 125 | 125 | 125 | 125 | |
| c | 70 | 70 | 70 | 70 | 70 | 100 | 100 | 100 | 100 | 125 | 125 | |
| d | - | - | 80 | 80 | 100 | 100 | 100 | 100 | 100 | 125 | 125 | |
| e | 70 | 70 | 70 | 70 | 80 | 100 | 25 | 25 | 25 | 25 | 25 | |
| f | - | - | 70 | 70 | 125 | 125 | 125 | 125 | 125 | 150 | 150 | |
| g | 70 | 70 | - | - | - | 100 | 100 | 100 | 100 | 125 | 125 | |
| h | - | - | 70 | 70 | 80 | 100 | 125 | 125 | 125 | 150 | 150 | |
| Outlet | 70 | 70 | 80 | 80 | 80 | 100 | 100 | 100 | 125 | 125 | 125 | |
| Jecket nozzle | Inlet(outlet) | 3-20 | 3-20 | 3-25 | 3-25 | 3-32 | 3-32 | 4-50 | 4-40 | 3-50 | 3-65 | 4-65 |
| Spray mouth | - | - | - | - | - | - | - | 2-50 | 2-65 | 3-65 | - | |
| Reference Weight (Kg ) | 463 | 530 | 700 | 984 | 1213 | 1909 | 2441 | 2693 | 4060 | 5186 | 5844 | |
Main Specification of K Type Glass-lined Reactor
Zibo Tanglian Chemical Equipment Co.,Ltd., as one of the most famous manufacturers of various chemical equipment in China , and with over 20 years export business experiences , we have sold our products to all provinces in China and over 30 countries in different continents all over the world .
We are keep develping the overseas market , and wish can be your reliable supplier and parterner .
Question: Are you a real factory?
Reply: Yeah. we are a real factory of glass lined enquipment and stainless steel equipment. And our factory have over 20 years history. Welcome anytime.
Question: What is the daily output of your equipment?
Reply: 1500sets per year.
Question: How about your quality warranty?
Reply: We have strict inspection for the equipment before loading, and have one year quality warranty if the customers use the goods under the correct operation.
Question: How about the MOQ? How about delivery time?
Reply:
01 MOQ: 1set
02 Delivery time in accordance with the production time,30-60 days to the port of departure.
