Basic Info.
Model NO.
INF7503
IP Rating
IP68
Certification
ISO
Customized
Customized
Material Code
AISI 316L/DIN 1.4404 with 3.1 Certificates
Tight Tolerance
0.02
Pressure Rating[Bar]
100 Bars
Surface Roughness
Rtmax 2.5
Runout Tolerance
<0.03mm
Cylindricity
<0.03mm
Surface Flatness
<0.02mm
Surface Energy
>36mn/M
Rotatable Design
345°
Transport Package
Carton Box and Plastic Tray
Specification
35*35*30
Trademark
DTK
Origin
China
HS Code
9026900000
Production Capacity
100000 PCS/Year
Product Description
IATF16949 and ISO 9001 certified precision CNC machining service company, started in 2006, Infinity provides customers with more than 1 million sensor components every year, such as the sensor housing, processing connectors, adapters, mounting rods, and mounting plates for flow sensors, pressure sensors, and temperature sensors. Product materials include stainless steel, copper alloy, aluminum alloy, and special alloys. The complex, precise, reliable, and safe manufacturing process ensures the high-quality requirements of customers' products.
With over 3000m2 production workshop, Infinity company provides whole processing from material cutting to inspection & packing and shipment service.
With over 3000m2 production workshop, Infinity company provides whole processing from material cutting to inspection & packing and shipment service.
Production Inspection Process
Infinity Industries, Inc. provides customers with complete inspection services, from first article inspection, to process random inspection, and final inspection, all of which are implemented in strict accordance with the customer's drawings.
Our Quality Plan
Packaging & Logistics In principle, all legal requirements must be complied with in our packaging and logistics process. These are in particular:
- dangerous goods regulation
- national/international regulations for the treatment of wooden pallets
- requirements of sea freight, if necessary
- requirements of air cargo, if necessary
- packaging directives from our customers
Further applies to:
- The transport safety always rests with the consignor. Regarding cargo securing the legal regulations apply according to StVO and HGB and the VDI Guideline 2700.
- Infinity Company shall treat the goods during storage and shipping in such a way that the agreed-upon quality standard is preserved.
- The storage at our location shall be made according to the FIFO principle.
- All packaging materials must be free of attached silicone (e.g. silicone oil) and contain silicone.
Environmental Requirements / Occupational Safety
No danger to humans or the environment may occur through the delivery of the products. Hazardous materials (dangerous goods) must be labeled in such a way that the dangers are easily recognizable and visible from the outside.
- Individual packs / reusable packaging / refillable containers should not exceed an individual weight of 15 kg.
- The packing height of the loading unit must not exceed a maximum of 1600 mm.
- The maximum weight of the load unit must not exceed 1200 kg.
- The maximum dimension of pallets must not exceed 1200 mm x 1000 mm.
- Individual packs / reusable packaging / returnable containers/cargo units must not be damaged.
- Loading units must be accessible (at least 100 mm lower ride height).
Inner & Outer packaging:
